SlimPatio 68

Panoramic view and comfort

SlimPatio 68 is a high insulated sliding system with slim profiles and a concealed frame that combines comfort with elegance. Thanks to the ultra slim design, this sliding window allows for maximum natural light and provides an optimal panoramic view. The integrated innovative technologies guarantee ultimate performances with regard to wind and water tightness and thermal insulation, meeting with the highest standards.

The sliding system SlimPatio 68 offers you all design freedom to create contemporary living spaces,combining ultimate brightness with maximum comfort.


Visible width meeting section34 mm

Max. height vent2700 mm

Max. width vent2700 mm

Max. weight vent (element)250 kg

Overall system depth frame120 mm

Overall system depth vent64 mm

Rebate height18 mm

Visible height meeting section 4 doors74 mm

Min. Glass thickness24 mm

Max. Glass thickness36 mm

Glazing methodDry glazing with EPDM or neutral silicones

Thermal breakFibreglass Reinforced Polyamide Strips



Air tightness max. test pressure4 (600 Pa)

Water tightness8A (450 Pa)

Wind load resistanceB5 (2000 Pa)

Acoustic performanceRw (C; Ctr) = 40 (-2;-4) dB


Burglar resistanceRC2/WK2


Thermal insulation (Uf)2.4 W/m²K
